BFS Bacteria Free Plastic Container Blow&Fill&Seal System
BFS Bacteria Free Plastic Container Blow&Fill&Seal System
The biggest advantage of Blow&Fill&Seal(BFS)technology is preventing external contamination,such as human interference, environmental contamination and material contamination.Forming, filing and sealing containers in a continuous automated system, BFS will be the development trend in the field of bacteria free production.It is primarily used for liquid pharmaceutical applications, like ophthalmic&respiratory ampoules,saline or glucose solution bottles,etc.
Main technical parameters
| Model | Unit | JWZ-BFS-03-145S | JWZ-BFS-04-110S | JWZ-BFS-06-080S | JWZ-BFS-08-062S | |||
| Productvolume | ml | 0.4-2 5-1010-20 | 0.4-1 1-3 5-20 | 500 | 1000 | 100 | 250 | 500 |
| Die head Cavity | 3 3 3 | 4 4 4 | 6 | 6 | 8 | 8 | 8 | |
| Center distance | mm | 145 145 145 | 110 110 110 | 80 | 80 | 62 | 62 | 62 |
| Mold cavity | 3×(5+5)3×7 3×6 | 4×10 4×8 4×5 | 6 | 6 | 8 | 8 | 8 | |
| Total cavity | 30 21 18 | 40 32 20 | 6 | 6 | 8 | 8 | 8 | |
| Cycletime | second | 12 12 12 | 12 12 12 | 18.5 | 20 | 14.5 | 16 | 18.5 |
| Output | per hour | 900063004500 | 900063004500 | 1150 | 1080 | 1950 | 1800 | 1550 |
Note:The specifications are subject to changewithout prior notice.
Add:No.18,Dong'an Road,Chengxiang Industrial zone,Taicang,Suzhou city,China Whatsapp/Wechat/Mobile:+86-13601907989
E-mail:saldf@jwell.cn
Plastic Medical Straw Tube/Dropper Blow Molding Machine
Disposable plastic straw pipe/dropper is widely used in laboratory,food research,medical industrial etc.Spec- ifications are 0.2ml、0.5ml、1ml、2ml、3ml、5ml、10ml Etc.
Main technical parameters
| Model | Unit | BMO2D |
| Maxproduct volume | 2 | |
| Dry cycle | Pc/h | 900*2 |
| Die head structure | Continuous type | |
| Main screw diameter | mm | 65 |
| Maxplasticizing capacity(PE) | kg/h | 70 |
| Driving motor | Kw | 22 |
| Oil pump motor power(Servo) | L | 11 |
| Clamping force | KW | 40 |
| Space between platen | KN | 138-368 |
| Platen size W*H | mm | 286*330 |
| Max.mould size | mm | 300*350 |
| Platen moving stroke | mm | 420 |
| Heating power of die head | KW | 6 |
| Machine dimension L*W*H | m | 3.0*1.9*2.4 |
| Machine weight | 5 | |
| Total power | KW | 45 |
Note:The specifications aresubject to change without prior notice.
Plastic Hospital Bed Blow Molding Machine
Performance and advantages
●Suitable for producing different kinds of plastic medical bed head boards、foot boards and guardrails.
●Adopt high output extrusion system,accumulating die head.
●According to the different material,optional JW-DB single station hydraulic screen-exchanger system.
●According to the different product size,customized the platen type and size.
Main technical parameters
| Model | Unit | BM100 BM160 |
| Maxproduct volume | 100 160 | |
| Dry cycle | Pc/h | 360 300 |
| Die head structure | Accumulating type | |
| Main screw diameter | mm | 100 100 |
| Max plasticizing capacity(PE) | kg/h | 240 240 |
| Driving motor | Kw | 75 90 |
| Accumulating volume | L | 12.8 18 |
| Oil pump motor power(Servo) | KW | 30 30 |
| Clamping force | KN | 600 800 |
| Space between platen | mm | 500*1300 500*1400 |
| Platen size W*H | mm | 1020*1000 1120*1200 |
| Max.mould size | mm | 800*1200 900*1450 |
| Heating power of die head | KW | 30 30 |
| Machine dimension L*W*H | m | 5.5*2.5*4.0 7*3.5*4 |
| Machine weight | T | 16 20 |
| Total power | KW | 190 205 |
Note:The specifications are subject to change without prior notice.
